Specification sheet for Emit part 2

Sensitivity:

87dB (2.83V/1m)

IEC power handling:

180 watt

Impedance:

4 Ω

Frequency response (± 3 dB):

53Hz - 25kHz (-6 dB 46 Hz - 35 Khz)

Box principle:

Bass reflex rear double flared port

Crossover:

2.5-way

Crossover frequency:

1000/3500Hz

Crossover topology:

1ST order tweeter / 2nd order woofer

Specification sheet for Emit part 1

Midrange / Woofer:

14 cm MSP

Woofer:

14 cm MSP

Tweeter:

Cerotar soft dome with Hexis

Weight:

10.98 Kg / 24.2 lb

Dimensions (W x H x D):

550 X 170,1 X 271,5 mm

21.7 X 6.7 X 10.7 in

Dimensions with feet/grille (W x H x D):

550 X 170,1 X 284,5 mm

21.7 X 6.7 X 11.2 in
